Plans of the Josephine Mill

Abstract

Drawing of the plans of Josephine Mill, depicting foundations of the earlier mill, the Josephine Mill, outshuts, additions between 1863 and 1888 and additions 1986. The first floor depicts detail of steps down, 2 wooden and 2 iron posts, the original doorway, steps up, a raised floor, heating, a vent and a chimney stack. The ground floor depicts detail of a water-wheel, a cogged rim, a mill-race, a sliding hatch, 3 bearing boxes, a later opening, steps up, a section of a vault, a flue and a section of the ceiling with vents.
